Information
• Magnet mount included
• Ceramic Shaft
• Ceramic rotor bearing
• High flow rate
• Energy efficient
• Prop impeller rotor
• UL listed
Details
• Magnet Mount
Magnet Mount support system makes mounting of the pump quick and easy allowing the
pump to be secured virtually anywhere in the aquarium.
Note：
MM50 is for glass thickness up to 1/4in (7mm)
MM100 is for glass thickness up to 3/8in (10mm)
MM200 is for glass thickness up to 1/2in (12mm)
• 160° Directional Discharge
160° directional discharge enables the pump to be directed and secured at different angles.
• Prop Impeller
Prop impeller creates high water volume output with low pressure
making the pump energy efficient with low heat emissions.
Product Models
| Model | Watts | Pump Size L x W x H |
Flow Rate GPH |
|
| 115v 60Hz |
220v 50Hz |
|||
| SEIO P320 | 4.5 | 5.6 | 6.3 x 3.9 x 4.8 cm | 320 GPH |
| SEIO P530 | 7.5 | 3.0 | 8.3 x 4.9 x 5.9 cm | 530 GPH |
| SEIO P1000 | 11.2 | 5.7 | 10.8 x 5.5 x 6.6 cm | 1000 GPH |
| SEIO P1500 |
25 |
12 |
12 x 6.2 x 7.4 cm | 1500 GPH |
Part List
  |
1. Main housing strainer 2. Well cover lock nut 3. Impeller well cover 4. Bushing 5. Prop impeller 6. Ceramic shaft 7. Motor housing 8. Air tubing & silencer 9. Magnet mount 10. 160° directional discharge 11. Variable venturi intake |
Replacement Part
| Part number | Description |
| 5 | SEIO Prop Prop impeller |
| 6 | SEIO Prop ceramic shaft |
| 10 | SEIO Prop 530 160° directional discharge |
Installation
